FREQUENCY CONVERTER REOVIB MFS 368

More technology in the same form – this is the motto of the new REOVIB MFS 368. The new devices consume up to 45% less electricity. This means that they do not only offer a better energy footprint, but also lower operating costs. This has been achieved by reactive power compensation. The lower power consumption is more eco-friendly thanks to the reduction in CO² emissions.

The frequency converters also have impressive effects on the conveying technology, with a wide input voltage range of 99 V to 264 V for a consistent output voltage of 250 V max. They also make it possible to operate the vibratory feeder at the optimal vibration frequency for the conveyed goods, completely independently of the frequency of the supply electrical network. The device can therefore be used worldwide. Where several different conveyors or magnets would have been required in the past, one REOVIB MFS 368 can now get the job done.

It is also possible to automatically determine the resonance frequency of the vibration system and control the vibration amplitude to set it at constant values by implementing the REO-patented ACC control procedure. The benefit of this is that the conveyor automatically works at the optimum conveying capacity independently of the load or mechanical settings. No time-consuming adaptation of the conveyor is required. The new REOVIB MFS 368 means that optimum and maximum conveying performances can be consistently achieved, such as when springs age or with changing mechanical loads or voltage fluctuations.

The new inverter has an integrated active mains filter, which saves additional costs for an external mains filter and reduces power consumption, as well as an LCD display with full text display. A temperature sensor for magnets can be connected as an option, which guarantees that there are no failures due to defective magnets and increases the operational safety of the systems.

The devices can be optionally equipped with fieldbus interfaces and are also available in versions with UL/CSA certification. This enables uncomplicated use in systems in the USA and Canada without any effort or testing.

The devices of the REOVIB MFS 368 series are available with a max. output current of 3 A, 6 A , 8 A as IP20 variant for switch cabinet installation as well as IP54 housing version. The IP54 enclosures can be supplied with various connection options:

• Input cable/output cable
• Input cable/output socket
• Completely pluggable with input connector, output socket and sensor and actuator connectors
